Optikam measurements.

3D eyewear measurements

Your prescription describes lens power. Optikam records how your chosen frame sits in front of your eyes, helping our optical team plan lens positioning for that fit.

  • Eyewear walk-ins welcome.
  • Outside prescriptions accepted.
Illustrative Optikam measurement capture with a patient and optician.
Illustrative Optikam measurement capture.

Locating each lens

Lens alignment.

Your eyes provide reference points. The selected frame provides the setting for the lens design. These measurements describe where each lens is positioned horizontally and vertically.

Pupillary distances (PDs)
Optikam locates each pupil relative to the frame midpoint, describing horizontal lens alignment for the selected frame.
Fitting heights
Also called segment heights, these place the lens design vertically within the frame. They are especially relevant to progressives.

The frame in its worn position

Frame positioning.

Illustrative close-up of the Optikam Posture Device attached to eyeglasses.
Illustrative detail of the Optikam Posture Device.

Frame angle, curvature and distance from the eyes are part of the fitting picture. Optikam records these as-worn measurements for the eyewear you choose.

The Optikam Posture Device (OPD) provides reference points on the frame while the tablet captures the fitting image.

Pantoscopic tilt
Viewed from the side, this describes the lens plane’s forward tilt as the frame sits on the face.
Frame wrap
Viewed from above, this records how the frame curves around the face, rather than only its width.
Vertex distance
The gap between the back of the lens and the front of the eye. It describes lens position, rather than lens thickness.

Putting the information together

Measurements in context.

Illustrative review of fitting measurements with a patient and optician.
Illustrative review of fitting measurements.

Frame choice, lens design and how the frame sits all matter. Our team considers your prescription, lens options and chosen eyewear, then combines the fitting measurements with personal guidance and frame adjustments.

These measurements are especially relevant to progressive lens fitting and high-prescription lenses.

Optikam measurements are part of fitting eyewear bought at iDoctor. We do not offer standalone PD measurements.

A few helpful answers

About the measurements.

Can I bring a prescription from another eye doctor?

Yes. Outside prescriptions and walk-ins are welcome at the optical. You do not need an eye exam to explore eyewear. Our team can help you consider frames, lenses and the fitting measurements for your chosen glasses. If you need an updated prescription, our team can help arrange an eye exam.

Can I book a standalone PD measurement?

No. We use Optikam for eyewear purchased at iDoctor, and do not provide standalone PD measurements.

Are these measurements the same as my prescription?

They serve different purposes. Your prescription describes the optical correction. Fitting measurements help position and personalize lenses for the selected frame and how it sits on you.
